SPECIFICATIONS:
NOTES:
1）MATERIAL:
HOUSING:LCP S475 UL 94V-0
CONTACT:C5210-EH T=0.15mm
SHELL
SUS201-H T=0.20mm
2)FINISH
CONTACT:GOLD FLASH PLATED ON CONTACT AREA 1u‘’ Min
GOLD FLASH PLATING ON SOLDER TAILS 1u“” Min,
WITH ENTIRE CONTACT UNDERPLATED NICKEL 50u"Min
SHELL:NICKEL UNDERPLATED OVERALL 50u" Min,
3)MECHANICAL CHARACTERISTICS
CONTACT RETENTION:50gf/pin Min
MATING CYCLE:1500 CYCLES
4)ELECTRICAL CHARACTERISTICS
RATING CURRENT:1A
RATING VOLTAGE:12V
CONTACT RESISTANCE:50 MILLOHMS OHMS MAX
INSULATION RESISTANCE:a,UNMATED:1000M OHMS MIN
b,MATED 100M OHMS MIN
DIELECTRIC WITHSTANDING VOLTAGE:
500V AC/1MINUTE
OPERATING TEPERATURE:-25°C--+70°C
STORAGE TEMPERATURE:-10°C--+40°C
