SPECIFICATIONS
1.CURRENT RATING: 5.0A FOR Vbus PIN.
1.25A FOR VconnPIN.
0.25A FOR OTHERPINS.
2.CONTACT RESISTANCE 40mQ.
3.INSULATION RESISTANCE 1000MQ MIN.
4.DIELECTRIC WITHSTANDING VOLTAGE 500 VAC MIN.
5.OPERATING TEMPERATURE:-40°CTO+85°C.
6.MATING FORCE:5~20N.
7.UNMATING FORCE:8~20N.
8.DURABILITY:10,000 CYCLES.
9.RECOMMENDED PROCESS: THE PEAK TEMPERATURE ON THE BOARD SHALL MAINTAIN 260°C.
10.MATERIAL SPECIFICATION:
1).HOUSING:HIGH TEMPERATURE RESISTANT PLASTIC,UL94 V-0.BLACK
2).CONTACTS:COPPER ALLOY
3).SHELL:STAINLESS STEEL
11.PLATING SPECIFICATION:
2-1.CONTACTS:
Ni 50u"MIN.UNDER PLATED OVER ALL.
1u Au PLATED ON THE FUNCTIONAL AREA OF CONTACT.
Au GOLD FLASH PLATED ON SOLDER AREA.
2-2.SHELL:
Ni 30u″ MIN.UNDER PLATED OVER ALL.
